itel a23 frp lock solution

Itel a23 spd cpu frp lock solution

Itel a23  google account lock remove done by cm2 dongal.itel a23 have spd cpu with locked bootloader so that its can’t unlock by erase persist command.Follow these steps to unlock frp 100% ….

Test Report-

Card found: S/N : D8&&&& , v0135
Chinese Miracle II [SPD module] v 1.22

Loading : A23-SU335-8.1-IN-V010-20181017.pac
CRVersion : BP_R1.0.0
PacCPUinfo : sp9832e_1h10
PacVersion : A23-SU335-8.1-IN-V010-20181017
FastCheck : 0x0060AA2CD7

Loading files …

File : fdl1-sign.bin
File : fdl2-sign.bin
File : sharkle_pubcp_customer_Smart_Phone_nvitem.bin
File : prodnv.img
File : u-boot-spl-16k-sign.bin
File : SC9600_sharkle_pubcp_customer_Smart_Phone_modem.dat
File : SharkLE_LTEA_DSP_evs_on.bin
File : SHARKLE2_DM_DSP.bin
File : sharkle_cm4.bin
File : PM_sharkle_cm4.bin
File : boot.img
File : recovery.img
File : system.img
File : userdata.img
File : logo.bmp
File : logo.bmp
File : cache.img
File : u-boot-sign.bin
File : persist.img
File : sharkle_pubcp_customer_Smart_Phone_deltanv.bin
File : sml-sign.bin
File : vendor.img
File : tos-sign.bin
File : gnssbdmodem.bin
File : gnssmodem.bin
File : vbmeta-sign.img
File : sp9832e_1h10.xml
Load Ok!
Operation : Format File System / Reset Settings [ v1.22 ]
Settings : SmartFormat is On
Remove battery. Insert battery back
Press and hold ‘VolumeUp’ and ‘VolumeDown’ keys
Insert cable==== Wait for phone…
Phone found! [ 45 ]
Port Opened
Sync…
InitBoot Done [ 0x81 ] , Ver : SPRD3
Sync…
Sending FDL
[Info] : If SW freeze here more, than 15 seconds – remove cable
PickUp loaders from pac
FDL Ready!
Boot Ver : Spreadtrum Boot Block version 1.1
Sending FLASH FDL
FLASH FDL Ready!
Boot Ok!
FlashMode Set : Ok!
Checking Structure …
Detected eMMC Flash , Structure detect Ok!
eMMC phone detected! Will use ‘Safe Format’ mode!
UserData : PART_MOUNT failed! Part Damaged! Will use Repair Mode!
Mount : /cache
Size : 0x0000000007300000
State : 0x0001
Prepare Ok! Format Ok!
Don’t touch phone, until it fully bootup to “Welcome Screen”!

Download tested flash file from this link

Add flash file and do frp reset from service tab..download itel a23 flash file from upper link..

                                     ………………Best of luck…………..

!!!!Feel free to comment here if you have any query regarding this post!!!!

Lenovo A2016a40 frp unlock with sp tool only

Lenovo A2016a40 frp lock removed with sp tool only (without box)

Lenovo a2016a40 having mtk secure boot MT6735m.is not supported by many professional tool,like miracle box,umt,mrt ets paid tools.Many friends are searching for easy and quick solution to remove frp in lenovo A2016a40. Without full flash and without risk of dead after flash.Just go ahead and follow given guide to perform frp unlocking easily.

process ..

  • Download sp flash tool for Lenovo A2016a40
  • Download frp unlock files for A2016a40 By Technocare
  • Download and install mtk preloader drivers if not installed before.
  • Extract sp tool and frp files folder and open tool.
  • Select download agent (da file) DA_SWSEC.bin
  • Select Scatter file MT6735M_Android_scatter.txt from frp files folder.(as shown in billow picture)
  • Go to format tab of sp tool and tick manual option(follow billow picture for detail)
  • Enter manual format addr. or copy paste from here
  •                                                              Begin Address[HEX]:   0x6A00000
  •                                                             Format Length[HEX]: 0x100000
  • Click on start and insert usb cable to phone. (if got error then press and hold volume up key while connecting usb)
Lenovo a2016a40 frp unlock
Lenovo A2016a40 frp files
Lenovo A2016a40 frp unlock files


Select correct DA file from folder

Select correct scatter file from folder
Download tool by given link do not try with other version of sp flash tool to unlock phone without any error

Enter manual format addr. correctly other voice you will kill the phone
Must installed mtk preloader drivers in pc before process if not installed before.download it from here

Best of luck-

..Feel free to comment here if you have any query regarding this post..

Lenovo A6600d40 Frp unlock done with sp tool only

Lenovo A6600d40 frp unlock without box-sp tool only

Hey guys in this post you will found how to reset google account lock in lenovo a6600d40 without flashing full file or using paid boxes.By this method you can simply unlock frp lock in lenovo a6600d40 with sp flash tool and frp unlock files only.For detailed guide follow steps billow..

Lenovo A6600d40 have secure boot mtk mt6735m cpu.and not supported by many tool properly..

  • Download sp flash tool for Lenovo a6600d40
  • Download frp unlock files for A6600d40 By Technocare
  • Download and install mtk preloader drivers if not installed befor download it from here
  • Extract sp tool and frp files folder and open tool
  • Select download agent-DA FILE – DA_SWSEC_CRYPTO20_0217.bin
  • Select Scatter file MT6735M_Android_scatter.txt from frp files folder (as shown in billow picture)
  • Go to format tab of sp tool and tick manual option(follow billow picture for detail)
  • Insert manual format addr.
                                                                Begin Address[HEX]:   0x6A00000
                                                                Format Length[HEX]: 0x100000
  • Click on start and insert usb cable to phone. (if got error then press and hold volume up key while connecting usb)
Lenovo a6600d40 frp files
A6600d40 frp unlock

NOTE..

Select correct DA file from folder

Download tool by given link do not try with other version of sp flash tool to unlock phone without any error

Select correct scatter file from folder

Must installed mtk preloader drivers in pc before process if not installed before download it from here

!!!!! Feel free to comment here if you any query regarding this post we will happy to help you !!!!!
